Semi-auto Biochemistry Analyzer YC-10

YC-10 is an afforable but very reliable Semi-auto biochemistry analyzer using LED as light source which makes it nearly no need maintenance, it has a very compact design, almost the smallest in its class, users are able to own a high quality semi-auto biochemistry analyzer with the least cost.

Categories: ,

1. Key Features

LED as the light source, longer life, nearly no need maintenance

Very compact and unique design, smallest in its class

Afforable yet remains high quality and duration



2. Main Specifications

Light source: LED cold light source, maintenance-free

Test Methods: End-point, Kinetic, two-point kinetic/fixed time method, single/dual wavelength;

Wavelength: 7 standard filters(340nm, 405nm, 450nm, 505nm, 546nm, 578nm, 630nm), 1 optional channel;

Incubation position: 10 standard incubation positions

Test Temperature: Multi-temperature selectable test positions(25, 30, 37 degrees)

Display: 7.0-inch touch screen, 1024*600 IPS full-color high-definition viewing angle

Printer: Built-in thermal printer, 57mm paper, support customized print format

Flow cell and optical path: 32ul, 10mm, support cuvette

Resolution: 0.0001Abs

Luminosity Range: 0.000-4.000Abs

System environment: Linux+Qt

Memory: 8GB, 300+programs, 200,000+ results storage

Operating Environment: Temperature 10℃-35℃, humidity 30%-85%

Power requirements: Wide power supply AC 100V-240V, 50/60Hz

External Interface: 1 WLAN, 2USB

Instrument weight: 3KG

Instrument size: L270mm*W250mm*H130mm

Multi-language: Customizable

Reagents: Open system

LIS: support

Reagents:

Liver function: ALT, AST, ALP, ALB, CHE, TBA, ADA, TP, YGGT, TBIL, DBIL, GLDH, PA, GPDA, SA

Blood Lipids: CHO, TC, TG, HDL-C, LDL-C, APOA, APOB, LP

Renal Function: CREA, UREA, UA, MALB, CYC-S

Glucide: Glu, HbA1c

Immunoproteins: IgA, IgG, IgM, C3, C4, IgD, CRP, IgE, ASO

Electrolyte and Inorganic Ion Reagent: Ca, Mg, CO2, P, K, Na, Fe

Cardiac Function: CK ,CKMB, LDH, cTnI

Pancreas: AMY, PAMY, LPS



OEM, SKD are very welcome. Other customized functions are possible, you are welcome to negotiate for different solutions.
